PVC Coated Fabric
DESCRIPTION
PVC tarpaulin is a three-ply fabric consisting of a piece of scrim laminated between two sheets of polyvinyl film (PVC). Scrim is loosely woven material which can be made out of cotton, fiberglass, nylon, polyester, or a combination. The polyester is measured by the weights of the thread (denier) and the density of the weave (threads per inch) or count. The heavier the weight the higher the denier. The polyvinyl chloride (PVC) films were complemented by polyurethane films and coatings, silicone coatings, acrylic coatings, and blended rubber coatings. All of these films and coatings are reinforced with nylon and polyester fabrics which are non-woven, woven, and knits. There are many other films, fabrics, and foil that can be coated and laminated for a variety of special applications. We can produce laminated and coated PVC tarpaulin, for its good flexibility, excellent tensile strength and tear strength and develop all kinds of durable PVC tarpaulin materials for different applications.
|
Description
|
Base Fabric
|
Weight(g/sqm) |
Width(m)
|
|
|
|
900
|
1.6/2.5/28/3/3.2
|
|
1050
|
1.6/2.5/2.8/3/3.2 |
||
1300*1300 D, 30*32/sq.in | 1100 | 1.6/2.5/2.8/3/3.2 | |
1500*1500D，30*32/sq.in | 1200 | 1.6/2.5/2.8/3/3.2 | |
Semi coated Tarpaulin | 610 (18oz) | 1.6/2.5/2.8/3/3.2/5 | |
650 (19oz) | 1.6/2.5/2.8/3/3.2/5 | ||
750 (22oz) | 1.6/2.5/2.8/3/3.2 | ||
1000*1000D, 28*26/sq.in | 1050 | 1.6/2.5/2.8/3/3.2 | |
500*500D, 18*17/sq.in | 450 | 1.6/2.5/2.8/3/3.2/5 | |
300*500D, 18*12/sq.in | 500 | 1.6/2.5/2.8/3/3.2/5 | |
840* 840D, 9*9/sq.in | 550 | 1.6/2.5/2.8/3/3.2/5 | |
1000*1000D, 9*9/sq.in | 600 | 1.6/2.5/2.8/3/3.2/5 | |
1000 *1000D, 18*16/sq.in | 680 | 1.6/2.5/2.8/3/3.2/5 | |
|
|
600*600D
|
550
|
1.83/2.08
|
600*900D | 580 | 1.83/2.08 | |
900*900D | 650 | 1.83/2.08 |
Technical datasheet:
|
Base Fabric |
1000*1000 9*9 | 1000*1000 12*12 | 1000*1000 20*20 |
1000*1000
23*23 |
1000*1000
30*30 |
Test Method
|
|
Weight |
410-680gsm | 450-680gsm | 550-750gsm |
680-900gsm
|
900-1100gsm
|
D1N53352
|
|
|
Tensile Strength (N/5CM)
|
L | 1300 | 1800 | 2500 |
3000
|
4000
|
|
W | 1300 | 1500 | 2200 | 2800 | 3500 | ||
Tearing Strength (N/5CM) | L | 200 | 220 | 260 | 360 | 600 | |
L | 190 | 180 | 230 |
350
|
500
|
||
Adhesion (N) | 70 | 70 | 100 | 100 | 100 | D1N533557 | |
Following is our PVC Coated Fabric categories for different technology and applications, click image to view product list for each type:
You Can Choose Following Products
52 products found
Our standard material for truck covers is a high tenacity polyester fabric coated on both side with UV stabilized PVC.
Most tents namely commercial and large event tents are all made of PVC or Polyvinyl chloride fabric.
Our standard material for truck covers is a high tenacity polyester fabric coated on both side with UV stabilized PVC.
Most tents namely commercial and large event tents are all made of PVC or Polyvinyl chloride fabric.
Our standard material for truck covers is a high tenacity polyester fabric coated on both side with UV stabilized PVC.
Our standard material for truck covers is a high tenacity polyester fabric coated on both side with UV stabilized PVC.
Most tents namely commercial and large event tents are all made of PVC or Polyvinyl chloride fabric.
Roll up door fabric for industrial door which is commonly used business facilities.
PVC Flexible Air Duct Fabric is an innovative and cost-effective fabric alternative to traditional metal ductwork.
Inflatable fabrics are PVC coated or laminated with synthetic materials to increase their strength and environmental resistance
Fabricated from heavy duty 1000D High Tenacity Polyester fabric coated on both side with UV stabilized PVC.
This Transparent Leno Fabric is made from PVC and high-strength polyester mesh.
PVC Knitted Drop Stitch Fabric is becoming increasingly popular with applications such as inflatables, gym mats and more.
Drop stitch material consists of two parallel sheets of fabric that are connected by thousands of polyester threads.
It features a reinforced PVC knitted drop stitch construction that provides outstanding strength, stability, and longevity.
PVC Drop Stitch Fabric is a pretty amazing material to build SUP Boards, inflatable drift boats and the Fishing Watercraft.
PVC Knitted Drop Stitch Fabric is becoming increasingly popular with applications such as inflatables, gym mats and more.
Textilene Solar Screen Fabric offers maximum transparency with a high degree of glare protection.
PVC Coated Textilene Mesh Fabric is made of polyester yarns individually PVC coated, woven to become durable fabrics.
PVC mesh fabric is an open weave, durable and flexible fabric.
PVC Mesh Sun Screen Fabric offers maximum transparency with a high degree of glare protection.
PVC mesh fabric is an open weave, durable and flexible fabric.
The three-layer design of PVC Canvas offers maximum breathability and durability.
The three-layer design of PVC Canvas offers maximum breathability and durability.
The three-layer design of PVC Canvas offers maximum breathability and durability.
Most tents namely commercial and large event tents are all made of PVC or Polyvinyl chloride fabric.
Most tents namely commercial and large event tents are all made of PVC or Polyvinyl chloride fabric.
Most tents namely commercial and large event tents are all made of PVC or Polyvinyl chloride fabric.
Tensile membrane structures take shade coverings and translate them into a whole new level of architecture.
Tensile membrane structures take shade coverings and translate them into a whole new level of architecture.
High speed doors is the term commonly used for doors whose curtains are made from plastic tarpaulins.
PVC Flexible Air Duct Fabric is an innovative and cost-effective fabric alternative to traditional metal ductwork.
PVC Flexible Air Duct Fabric is an innovative and cost-effective fabric alternative to traditional metal ductwork.
PVC Coated Mesh Tarps, can be used in windscreens, privacy fence, construction site safety fence.
Inflatable fabrics are PVC coated or laminated with synthetic materials to increase their strength and environmental resistance
PVC privacy screen is extremely tear-resistant fabric constructions suitable for single- bar and double-bar fencing.
Inflatable fabrics are PVC coated or laminated with synthetic materials to increase their strength and environmental resistance
Inflatable fabrics are PVC coated or laminated with synthetic materials to increase their strength and environmental resistance
Is a special material with excellent durability, tearing strength, water and U.V resistance.
